|SERVICE PLAN (INCLUDING UNLIMITED ACCESS AND ALL DATA COSTS||MONTHLY FEE PER DEVICE (INC GST)|
|Track Asset Monthly Service Fee||$19|
The SU-8000 X is different, much different .
Measuring only 96mm x 50mm x 18mm , the compact design is just the start. The SU-8000X has four intelligent sensors enabling the delivery of critical information that is required when tracking valuable cargo or where cargo integrity.
This will trigger location report if the asset is moving, or if the cargo is mishandled
The on-board temperature sensor will provide temperature readings throughout the journey from A to B
The on-board humidity sensor will provide humidity readings throughout the journey from A to B
Light Sensor – Chain of Custody
The light sensor will trigger in the event the cargo is exposed to light. This feature is ideal for tracking cargo that should not be opened for example evidence.
In addition to the sensors, the SU-8000 X is powered by a rechargeable 2500 mAh battery giving 3 months battery life per charge.
The compact housing is made of sturdy ABS plastic. It clips together, requiring no screws.
Dimensions: 97 mm x 52 mm x 18 mm
Weight:110 grams with battery pack
2500mAh 3.7V, temperature controlled charging.
USB Micro 5V input, 500mA. USB cable included.
10uA (micro amps) with accelerometer on and other sensors off.
Battery Life with Adaptive-Tracking
The SU-8000X can be set to use Adaptive-Tracking technology where the accelerometer and GPS data are used to intelligently work out if it is moving and to send frequent updates, and to scale the update rate down to once per day if the asset is stationary – to preserve battery life.
18 months @ one position per day (at 25°C)
-20°C to +60°C (discharge only)
0°C to +45°C (temperature controlled)
Precision Relative Humidity Sensor. ± 3% RH (max), 0–80% RH.
High Accuracy Temperature Sensor. ±0.4 °C (max), -10 to 85 °C.
SU-8000x housing may need modifications for responsive measurements.
On PCB with a light pipe through the housing.
0.045 – 188’000 Lux.
Configurable anti-tamper can report on light change.
High sensitivity GPS
UBLOX MAX-M8Q GPS module
Supports concurrent GPS and GLONASS
72 channel high sensitivity receiver
-167dBm industry leading tracking performance
Optimal hot-start performance
AssistNow Offline aiding data for fast time-to-first-fix and performance in urban canyon environments
The SU-8000x uses both the GPS and GLONASS positioning systems simultaneously.
This allows the device to use twice the number of satellites to get a position fix – making it faster and more accurate.
Low noise GPS amplifier
GPS signals are boosted by a special low-noise amplifier (LNA)
This allows the SU-8000x to operate where normal units will fail to receive GPS signal – like in a container stack!
The SU-8000x uses a micro-SIM card holder (3FF form factor)
The SU-8000x can be manufactured for specific markets around the world depending on their modem requirements:
3G Modem is standard in Australia
Internal GPS and Cellular RF antennas tuned by the RF laboratories to ensure optimal performance
3 axis accelerometer
The 3-axis accelerometer allows the SU-8000x to ‘sleep’ in an ultra-low power state yet still wakeup when movement occurs.
Future firmware versions will allow for harsh G-force detection (like assets being dropped or involved in accidents)
The SU-8000x has enough flash to store over 25,000 data records, and will record information even when out of cellular coverage.
The flash memory is also used to store firmware updates, GPS aiding data, parameters and other important information.
A future firmware version will allow for geo-fences to be loaded into the flash memory of the device and used for geo-fence alerting on the device.
